PRODUCT INTRODUCTION

Compact DC High Voltage Pulse Module

This high voltage dc generator is widely used in various fields such as electronic protective equipment, security equipment, security flashlights, taser guns, high-voltage power grids, farm power grid electric fences, electronic shields, protective gloves, spark plug testing and so on.

Its working principle is that the high-voltage generator is powered by DC power supplies of different volts, and the transformer is driven by an oscillation circuit to boost the voltage once, and the voltage is boosted twice by the voltage doubler rectifier module, and finally a DC high voltage discharge is formed.

Miniature DC Pulse High Voltage Generator

Product name	dc high voltage module
Model	TW-G-AF-6S
Input Voltage	3.7VDC
Output voltage	15-20KVDC
Igniting distance	8mm
Working Current	2600mA
Size	L33mm×W7mm×H39mm
Input Line Diameter	1.2±0.03MM
Output Line Diameter	1.6±0.03 MM
Copper Wire	0.15 mm x 7 Φ root
Input Line Length	40 MM
Output Cable Length	60 MM
Weight	25±1g

High Voltage Output

Features:

DC 3.6V high voltage generator module based on the tesla coil principle, output high voltage pulse current with simple circuit design, easy to use

This module used for the production of science with high voltage inverter transformer and booster module.

2.Finished product after input DC3.6 V voltage can be obtained at the output end of around 12kv dc high voltage arc (about 1 cm),

3.It can be used as a high school science experiment, electronic instruments, small anion generator, scientific production of high voltage source is used.

4.Because of high power,low heat-sinking capability of the internal, the module can‘t work for long time.

5.Small size. High efficiency

Package Contents: 1 x High Voltage Generator inverter

Compact & Lightweight

Advantage:Tianwang is specialized in the R&D and production of high voltage module and generator for 30 years. We have fully automatic production machines and strict quality inspections. The product production cycle is short and the quality is guaranteed. The products sold have stable performance, long life, and are not easy to damage.

1.Rich production experience and technical capability, sophisticated production and testing equipment, advanced production and processing technology.

2.We can provide customized design, product proofing, professional testing, and solving your worries

We have strong R&D, design, brand operation team, and we have technical cooperation with many universities.

3.From the moment you contact us, we will provide you with dedicated service, clearly grasp your needs, provide you with personalized and personalized services, and try our best to meet your requirements.
