4.5V stove pulse igniter
Our company founded in 1990.We are mainly engaged in Tianwang high-voltage generator, pulse ignition coil,high voltage generator and other high-voltage electronic products' development, production and sales.
一、technical requirements：
- rated operational voltage：4.5V
- operating voltage range：2.5~4.95V
- initial firing current：DC4.5（80~125mA）
- Output high voltage：≧12KV
- Discharge pulse width: ≧12us
- Discharge energy：≧1.0MJ
- Frequency of ignition：DC4.5V（9~13Hz ）
- DC2.5V≧4Hz
- Arcing distance：≧5㎜
- Discharge spark: arc blue and white the connecting wire bears tension≧25N
- Line type adopted 22AWG 1007，wire diameter：Ф1.5±0.1㎜
- The casing is yellow wax tube
- trademark: our furnace pulse labeling
二、4.5V Insert common double furnace
Detail of wire
|
serial number |
Description |
specifications and models |
colour |
QTY |
|
|
1 |
Left switch wire |
4.8Spring sleeve sheath/Length of wire 450±5mm |
Casing length 350±10mm |
yellow |
1 |
|
2 |
Positive power cord |
4.8Spring sleeve sheath/Length of wire 550±5mm |
(closed set) Length of casing 350±10mm |
red |
1 |
|
3 |
Negative power cable |
4.8Spring sleeve sheath/Length of wire 450±5mm |
black |
1 |
|
|
4 |
Earth circle line |
∅4.2Ring/wire length 240±5mm |
purple |
1 |
|
|
5 |
Right switch wire |
4.8Spring sleeve sheath/Length of wire 450±5mm |
Casing length 350±10mm |
green |
1 |
(The wiring does not include terminal length）
